Micro-X Rover Plus

Rover Plus: Uncompromised Mobile Imaging

Meet the Micro-X Rover Plus, a revolutionary mobile X-ray system engineered to bring high-quality imaging directly to the patient bedside. Utilizing breakthrough Carbon Nano Tube (CNT) Technology, the Rover Plus delivers the power and image quality of a fixed system in an ultra-lightweight, highly maneuverable package.

Weighing just

247 lbs (112 kg)

, this system is designed to navigate crowded hospital corridors and patient rooms with ease. Its compact design (Height:

1300 mm

in transport position) and

72 Vdc

Lithium Ferro-Phosphate (LFP) battery bank ensure it’s ready for any challenge, any time.

The powerful $9 kW$ generator provides a technique range from $40 kVp$ to $120 kVp$ , capable of supporting examinations on both pediatric and adult patients. Coupled with a $15.6″$ Full-HD Imaging Station and full DICOM 3.0 compliance, the Rover Plus integrates seamlessly into your clinical workflow. It truly is a “rad room on wheels”.

Experience the future of mobile radiography.

Key Features

The Micro-X Rover Plus delivers uncompromising performance and mobility, built around groundbreaking Carbon Nanotube technology.

Nano-Powered X-Ray

Features state-of-the-art Carbon Nano Tube (CNT) Technology with a stationary anode, providing reliable and consistent image output.

True Mobility

Remarkably lightweight, with a total weight of only 247 lbs ( $112 kg)$ , making it exceptionally easy to transport at walking speed.

High-Fidelity Power

Maximum power output of $9 kW$ , capable of a wide technique range from $40 kVp$ to $120 kVp$ .

Extended Reach

The vertical focal spot position ranges from a minimum of $712 mm$ up to a maximum of $2148 mm (84.6 in)$ when fully extended.

Watch and Learn: More about the Micro-X Rover Plus

Precision-Engineered for Clinical Excellence

The Rover Plus isn’t just a mobile unit; it’s a precision-engineered diagnostic instrument. Review the official specifications for the MXU-RV35 model, including component ratings, operating ranges, and regulatory compliance. We provide full transparency on key performance metrics such as mAs accuracy () and detailed movement forces, ensuring you have the data needed for system integration and acceptance testing. Click on the tabs below to find detailed figures on power output, physical dimensions, wireless protocols, and movement ranges.

X-Ray Tube & Generator

X-RAY TUBE (MXU-RV35)
Tube Type:	Carbon Nano Tube (CNT) Technology
Voltage Range:	40 kVp to 120 kVp
Current Range:	20 mA to 90 mA
Focal Spot Size:	Variable 0.9 to 1.9 (IEC 60336 equivalent)
Anode Input Power:	9 kW for 12 ms
Target Material:	Tungsten
Heat Capacity:	27 KHU (Anode)
Inherent Filter:	2.5 mm Al at 75 kV (IEC 60522)

Exposure Range (kVp vs. mAs)

X-RAY GENERATOR
Power Output:	9 kW
Technique Range:	mAs: 0.2 to 80 (per ISO Series R'20)
mAs Accuracy:	±(10%+0.2 mAs)
Linearity Coeff.:	≤0.1
Reproducibility:	0.05 for kVp and mAs parameters

Physical & Movement

PHYSICAL CHARACTERISTICS
Weight:	247 lbs (112 kg)
Height (Docked):	51.2 in (1300 mm)
Wheel Base Width:	22.9 in (583 mm)
Length (Docked):	53.9 in (1371 mm)
Max. Incline:	5 degrees (head in transport position)

X-RAY TUBE MOVEMENTS
Min Vertical Height:	28.03 in (712 mm)
Max Vertical Height:	84.6 in (2148 mm)
Arm Rotation:	±239 degrees
Tube Angulation (alpha)	±110 degrees
Head Tilt (tau):	−16 to +98 degrees

MOVEMENT & HOLDING FORCES
Vertical Movement Force (zeta):	53 N
Vertical Holding Force (zeta):	40 lbf (175 N)
Column Rotation Movement (beta):	20 N⋅m
Tube Tilt Holding Force (tau):	28 N⋅m (250 in lb)

Imaging & Connectivity

IMAGING STATION / CONSOLE
Display Type/Size:	LCD, 39.6 cm (15.6 in) viewable
Display Ratio:	Full-HD (1920 x 1080)
Operating System:	Microsoft Windows 10 LTSC 2019 (64-bit)
Processor:	Intel Core i5-7300U
Onboard Storage:	250GB SSD
DICOM Compliance:	Work List, Store, Print, MPPS, Store Commit

ELECTRICAL / BATTERY
Battery Type:
Number of Batteries:	5
Total Voltage:	72 Vdc
Charge Power Req.:	100 to 240 Vac, 50/60 Hz

WIRELESS COMMUNICATIONS
Network Protocol:	TCP/IP
Wireless Protocol:	802.11 a/b/g/n/ac
Frequency Band:	2.4 GHz and 5 GHz
Encryption:	WPA2-Enterprise or Personal (AES or TKIP)
Authentication:	EAP-PEAP-MS-CHAPv2, EAP-LEAP, EAP-PSK

Quality and Regulatory Certificates (OEM site) – 510(k) Premarket Notification (FDA site)

Rover Plus specifications (PDF) – Rover Plus sales brochure (PDF)

Brochures: Baseball (PDF) – Basketball (PDF) – Football (PDF)

Product Support & Contact

Support & Training

Software updates are upgradeable in the field.
Designed for maintenance and service by field technicians
Comprehensive training programs and user manuals available
